Use the exact series, type code and document revision when checking ratings, terminals, options, faults and regulatory records.
A useful drive document does more than name a product. It connects motor data, load duty, source characteristics, environmental limits, installation practice and control behavior to a traceable decision.
Motor nameplate, load torque profile, overload duration, supply voltage, fault-current context, ambient temperature, altitude, enclosure and protocol requirements.
One-line diagram, conductor and protective-device design, grounding and shield details, motor-cable length, cooling clearances, safety circuits and option-card locations.
Approved parameter set, I/O test record, network addresses, rotation check, loaded current trend, interlock proof, fault history and maintenance ownership.
Percentages illustrate the order of document completion, not project performance. A gate is complete only when the responsible engineer accepts its evidence.
Identify the applied standard and edition in the declaration or product manual.
Confirm the exact listed model, conditions of acceptability and market scope where applicable.
Match the declaration to the type code, directives and destination; do not infer coverage from a family name.
Retain measured supply voltage, loaded current, ambient, parameter backup and interlock results.
A compact selection near nominal current can reduce enclosure size and initial cost. Conservative current and thermal margin can improve tolerance for high ambient temperature, altitude, carrier-frequency losses and overload. Neither position is universally correct: compare measured duty, cooling design and lifecycle objectives, then document the chosen margin.
Validation can be reproduced by recording test conditions, loading the approved parameter set, operating at representative torque and speed points, logging input voltage, output current, DC-bus status and temperatures, and repeating the interlock sequence. Results remain installation-specific; they do not transfer automatically to another motor cable, enclosure or supply.
Send the type code or application worksheet and identify the decision that needs evidence.
